Delavan 6 Roller Pro Cast Iron Pump Kit DPK-6900C – Pumps

DPK-6900C – Cast Iron

Pump

Type: 6-Roller design

Max Pressure: 300 PSI (21 bar)

Max Recommended Temperature: 140°F (60° C)

Port Size: ¾” NPT (female)
6900: Side Ports
6601: Rear Ports – Non Field Serviceable

Mounting:
Base Mounted: 5⁄16 -18 UNC-2B (2 holes)

PTO: Use torque arm and coupler

Shaft:
Size: 5⁄8” solid shaft
Rotation: CCW (standard);
CW (optional)
(Shaft rotation is determined when
looking at shaft end of pump)

Weight: 9 lbs (19.8 kg)

Materials of Construction

Housing: Cast Iron or Diamond Series™ Stainless Steel

Rollers: 3⁄4” Ultra rollers (standard)
Polypropylene (optional)
6900 Series: 3⁄4” Ultra rollers (standard)
6601C: 11⁄16” Ultra Rollers (standard)
11⁄16” or 3⁄4” Polypropylene (optional)

Shaft Seals: Viton cartridge type lip seals

Seal Ring: Viton

Shaft & Rotor:
Cast Iron: Extra-fine finish 404 SST
Diamond Series™ Stainless Steel: Extra-fine finish 416 SST

Bearings: Permanently-lubricated, heavy-duty sealed bearings
